Material Dental 3D Multilayer Zirconia Blocks Dental Cad Cam Milling Machine
Product Features
Safety:No irritation,No corrosion,Good bio-compatibility
Beauty:Natural teeth color can be reproduced
Comfortability:Low thermal conductivity,hot and cold changes do not stimulte the pulp
Durability:Over 1600MPa perturbed strength, durable and useful
Sintering
Every batch of zirconia block has gone though a completely sintering test. The sintering methods have a great impact on blocks’ properties, such as translucency, dyeing results, strength, hardness and ageing resistance, which will affect the blocks’ final stability. Therefore, please follow the sintering curve of it.
The translucency of restorations is closely related to sintering temperature and regular maintenance of sintering furnace. Please follow the below temperature chart.
Zirconia Features
Zirconium dioxide porcelain tooth is a mineral that exists in nature as oblique zircon. Its density and strength are very high, the strength is 1.5 times higher than that of EMPRESS II, more than 60% higher than INCERAM zirconia, combined with unique crack resistance and strong curing performance after cracking, it can make porcelain bridges of more than 6 units. The problem that all all-ceramic systems cannot be used as long bridges is solved.
Zirconia Block Introduction
Yucera zirconia block has high strength, excellent permeability and color aesthetic repair effect that suitable for CAD/CAM system and manual system.
Product Features
Safety:No irritation,No corrosion,Good bio-compatibility
Beauty:Natural teeth color can be reproduced
Comfortability:Low thermal conductivity,hot and cold changes do not stimulte the pulp
Durability:Over 1600MPa perturbed strength, durable and useful
SHT/UT/3D multilayer Sintering Curve
| SHT/UT/3D multilayer Sintering Curve |
| Sintering step |
Start Temperature(℃) |
End Temperature(℃) |
Time(Min) |
Rate(℃/Min) |
| Step 1 |
20 |
900 |
90 |
9.7 |
| Step 2 |
900 |
900 |
30 |
0 |
| Step 3 |
900 |
1500 |
180 |
3.3 |
| Step 4 |
1500 |
15 |
120 |
0 |
| Step 5 |
1500 |
800 |
60 |
-11.6 |
| Step 6 |
800 |
natural cooling 20 |
120 |
-6.5 |
3D Multilayer Color Zirconia Block
* 6 layers multilayer color
* From 43-49% gradient for transparency
* Strength shows gradient from 600Mpa to 900Mpa
* Suitable for anterior, crown and bridge
Indications
Crown, Inlay, Onlay, 2-5 unit Bridges, Anterior,implant
